9/27/01
TABLE 9-4. Ball diameters for testing hose restrictions
or kinking.
HOSE SIZE
BALL SIZE
-4
5/64
-5
9/64
-6
13/64
-8
9/32
-10
3/8
-12
1/2
-16
47/64
-20
61/64
AC 43.13-1B CHG 1
FIGURE 9-11. Suggested handling of preformed hose.
Par 9-30
Page 9-25
