FAA Advisory Circular 43.13-1B
Acceptable Methods, Techniques, and Practices
Aircraft Inspection and Repair
AC 43.13-1B | 7. Aircraft Hardware, Control Cables, and Turnbuckles | 11. Hardware Identification Tables | 7-212. Pins
AC 43.13-1B
TABLE 7-15. (CONTINUED)
Pin Number
Description
AN416
Pin,
retaining safety
TABLE 7-15. (CONTINUED)
Pin Number
Description
MS9462-9468
Pin, straight
hd. AMS 5735
9/8/98
AN122676-122775
Pin, dowel steel
MS9486
Pin, straight, headless,
lock, AMS 5132
AN121601-121925
Pin, flathead clevis
.125 -.500 drilled shank
MS9842-9848
Pin, straight,
headed, AMS 5616
AN150201-150400
Pin, lock,
steel, brass
MS9047
Pin, spring, steel,
phoshated finish
MS16555
MS16556
Pin, straight,
headless .0002
over nominal size
Pin, straight, headless
.001 over nominal size
MS9048
Pin, spring, steel, cad-
mium plate
MS16562
Pin, spring,
tubular, slotted
MS9105
MS9164
Pin, lock
Pin, straight, steel,
headless, oversize
MS17984-17990
MS20253
Pin,
quick release,
positive lock
Pin, hinge
MS9245
Pin, cotter,
cres. AMS 7211
MS20392
Pin, straight,
headed, drilled
MS9389
Pin, straight, headless,
lock, AMS 5735
MS24665
Pin, cotter
MS9390
Pin, straight, headless,
cres. AMS 5735,
dowel std. & O.S.
MS35671-35679
Pin, grooved,
headless,
tapered groove
Page 7-72
Par 7-196
