AC 43.13-1B | 7. Aircraft Hardware, Control Cables, and Turnbuckles | 11. Hardware Identification Tables | 7-209. Bolts
AC 43.13-1B
TABLE 7-12. (CONTINUED)
Bolt Number
MS9088-9094
Description
Bolt, machine, steel,
drilled 12 pt. head
9/8/98
TABLE 7-12. (CONTINUED)
Bolt Number
MS9498-9508
Description
Bolt, mach. hex. hd.,
1 hole, full shank
MS9110-9113
MS9146-9152
MS9157-9163
MS9169-9175
MS9224
MS9397-9402
MS9432-9437
MS9440-9448
MS9449-9459
MS9487-9497
Bolt, machine, double
hex., ext. washer head,
close tolerance
Bolt, steel, 12 pt. hd.
black oxide 125,000 psi
min. T.S.
Bolt, steel, 12pt. hd.
black oxide 125,000 psi
min. T.S.
Bolt, steel, 12 pt. drilled
hd., black oxide
125,000 psi min. T.S.
Bolt, 12 pt. head, heat
resistant
MS9516-9526
MS9527-9537
MS9554-9562
MS9563-9571
MS9572-9580
Bolt, tee head,
AMS 6322,
chamfered cad. pl.
Bolt, tee head
AMS 5735 chamfered
MS9583-9591
MS9622-9630
Bolt, mach. steel.
AMS 6304 diffused
nickel cad. hex. hd.,
3 holes
Bolt, mach. steel,
AMS 6304 diffused
nickel cad., hex. head
Bolt, mach. hex. hd. full
shank, AMS 5731
MS9641-9648
MS9649-9652
MS9676-9679
Bolt, mach., steel
AMS 6322 cad.
1 hole hex. hd.
Bolt, mach., steel
AMS 6322 cad.
1 hole hex. hd.
Bolt, mach., dbl. hex.
ext. wash. hd., PD
shank, AMS 5731
Bolt, mach., dbl. hex.
ext. wash. hd. drilled,
AMS 5731
Bolt, mach., dbl. hex.
ext. wash. hd., drilled,
PD shank AMS 5731
silver plated
Bolt, mach., hex. hd.
6 holes full shank,
AMS 5731
Bolt, mach., hex. hd. 1
hole, PD shank, tita-
nium AMS 4967
Bolt, mach., hex. hd., 1
hole, full shank titanium
AMS 4967
Bolt, mach., hex. hd.
full shank, titanium
AMS 4967
Bolt, mach., dbl. hex.
ext. wash. hd., cup
washer locked, cres.
AMS 5731
